Place of Origin:
Hefei Anhui Province, China
Brand Name:
yiwan
Certification:
CE, ISO9001
Model Number:
automatic revolving door
Contact Us
With a production capacity of 20 sets per month, this Automatic Rotation Entry System is perfect for commercial applications that require high traffic flow. The Electric Revolving Turnstile is engineered to meet the demands of modern building designs, offering a range of customizable options to fit any architectural style.
The Canopy Height of this Automatic Revolving Door ranges from 300~600 mm, providing ample space for people to pass through while maintaining a comfortable and safe environment. The Power Driven Open Style ensures smooth and effortless operation, eliminating the need for manual intervention.
The Motor of this Automatic Revolving Door is Made in Germany, ensuring high quality and reliable performance. The advanced motor system ensures a smooth and silent rotation, minimizing noise and vibration. The customized Color options are available to match the specific design requirements of any project, providing a perfect integration with the surrounding environment.
The Automatic Revolving Door is an excellent solution for various applications, from office buildings and hotels to hospitals and shopping centers. It provides a secure and efficient access control system, preventing unauthorized access and enhancing the safety of the building occupants.
In conclusion, the Automatic Revolving Door is an innovative and reliable solution for modern building entrances, offering a range of customizable options to fit any architectural style. With its high production capacity, customizable colors, and advanced motor system, this Electric Revolving Turnstile is an excellent choice for any project that requires a seamless and efficient access control system.
Our Automatic Revolving Door product is a reliable and functional revolving access control unit that provides a range of features to enhance security and convenience. Featuring tempered glass and an external framework bearing, our motor-driven revolving gate offers safety and durability. With two working models, a windbreak, dust proof and noise insulation function, this product is effective in energy conservation and environmental protection. Our revolving door comes equipped with safety features such as anti-bump, anti-squeeze and anti-strike. Additionally, the access control function, operation modes selection, emergency stop button, disable button, battery backup, lockup/night function, stop as open state, stop as close state, speed adjustable, revers function, fire alarm, two show cases, LED display, and digital control system make our Automatic Revolving Door easy to operate and customize to fit your needs. Our product is CE and ISO9001 certified and made with durable aluminum material for long-lasting use.
| Open Style | Power Driven |
| Technical Data | |
| Power supply | 220V/50Hz |
| Rated current | 3.8A |
| Motor | 370W*2 |
| Revolving door drive unit | 550W |
| Down lights | 40W |
| High speed adjustment range (revolving door) | 3-4 r.p.m |
| Low speed adjustment range (revolving door) | 0.5-1.5 r.p.m |
| Aluminum thickness | >=3mm |
| System | Panasonic (Japan) |
| Glass | 6-8mm Glass |
| Surface treatment | #304 1.2mm Stainless Steel (Colour: optional) |
| Ceiling | Powder coated 1.2mm Aluminum Plate |
| Light | Energy-saving lamp |
| Dustproof Plate | 12mm Density Board |
| Control Operation LCD Panel | Panasonic Digital LCD screen, display and control the operation status of the door |
| Push Button | 1 set for each door (Install inside) |
| Production Capacity | 20 Sets/Month |
| Trademark | Yiwanx |
| Passage Height (mm) | 2300-3300 |
| Power Of Motor | 550 W |
| Inner Diameter (mm) | 2810-4610 |
| Transport Package | Export Wooden Carton |
| Material | Aluminum |
| Color | Customized |
The Automatic Revolving Door is made in Hefei Anhui Province, China, and has a supply ability of 20 sets/month. The delivery time is 30 days after receiving payment and the packaging details include a wooden case. The product is certified with CE and ISO9001, ensuring its quality and safety.
The Passage Height of the Auto-rotate Access Door ranges from 2300-3300mm, making it accessible for people of different heights. The technical data indicates that the Power supply is 220V/50Hz, with a rated current of 3.8A. The Motor is 370W*2, and the Revolving door drive unit is 550W. The down lights are 40W, and the High speed adjustment range(revolving door) is 3-4 r.p.m, while the Low speed adjustment range(revolving door) is 0.5-1.5 r.p.m. The Aluminum thickness is at least 3mm, and the System is from Panasonic (Japan). The Glass used is 6-8mm thick, with an optional color for the #304 1.2mm Stainless Steel surface treatment. The Ceiling is made of Powder coated 1.2mm Aluminum Plate, and the Light is an energy-saving lamp. The Dustproof Plate is 12mm Density Board, and the Control Operation LCD Panel is from Panasonic, with a digital LCD screen that displays and controls the operation status of the door. The Push Button is 1 set for each door (Installed inside).
The Automatic Revolving Door is suitable for various occasions and scenarios, such as banks, hotels, airports, shopping centers, office buildings, hospitals, and other public and commercial areas. Its modern design and advanced technology make it a perfect fit for high-end residential buildings as well. The product is available in customized colors and can be transported through sea or air, depending on the buyer's preference.
Payment terms for the Automatic Revolving Door include T/T and L/C. With its high-quality materials and advanced technology, the Auto-rotate Access Door is a great investment for any building that requires an elegant and efficient solution for controlling access.
Our Automatic Revolving Door product is designed and built to the highest standards of quality and reliability. However, in the unlikely event that you experience any technical issues or require maintenance services, we offer comprehensive product technical support and services to ensure that your Automatic Revolving Door continues to operate at peak performance.
Our technical support team is available to assist you with any questions or issues you may have regarding the operation of your Automatic Revolving Door. We can provide troubleshooting guidance, remote diagnostics, and on-site repair services as needed.
In addition, we offer preventative maintenance services to help you keep your Automatic Revolving Door in top condition. Our maintenance services include regular inspections, cleaning, and adjustment of all components to ensure optimal performance and longevity.
At our company, we are committed to providing our customers with the highest level of support and service. Contact us today to learn more about our product technical support and services for the Automatic Revolving Door.
Product Packaging:
This Automatic Revolving Door product will be packaged with care to ensure it arrives to you in perfect condition. The packaging will include:
Shipping:
We offer free shipping for this product to destinations within the United States. For international shipping, additional fees may apply. The estimated delivery time for this product is 5-7 business days from the date of order.
Q1: What is the brand name of the revolving door?
A1: The brand name of the revolving door is yiwan.
Q2: What is the model number of the revolving door?
A2: The model number of the revolving door is automatic revolving door.
Q3: What is the minimum order quantity for the revolving door?
A3: The minimum order quantity for the revolving door is 1 set.
Q4: What is the price range for the revolving door?
A4: The price range for the revolving door is between 3500-27500 USD per set.
Q5: What are the payment terms for the revolving door?
A5: The payment terms for the revolving door are T/T and L/C.
``` ```htmlQ6: Where is the revolving door manufactured?
A6: The revolving door is manufactured in Hefei Anhui Province, China.
Q7: What is the supply ability of the revolving door?
A7: The supply ability of the revolving door is 20 sets per month.
Q8: What is the delivery time for the revolving door?
A8: The delivery time for the revolving door is 30 days after receiving payment.
Q9: How is the revolving door packaged for delivery?
A9: The revolving door is packaged in a wooden case for delivery.
Q10: Is the revolving door certified?
A10: Yes, the revolving door is certified with CE and ISO9001.
