Name: China Factory Good Price Corner Doors Commercial Kfc Shop Front Store Front Door Double Automatic Swing Glass Entry Door
Brand: YIWANX
SKU: YW-125
Price: 80 USD
Availability: InStock
Rating: 5 (109 reviews)

Home > products > Automatic Swing Door >

China Factory Good Price Corner Doors Commercial Kfc Shop Front Store Front Door Double Automatic Swing Glass Entry Door

Double automatic Swing Glass Entry Door

Kfc Shop Front Store Front Door

Place of Origin:

HeFei, China

Brand Name:

YIWANX

Model Number:

YW-125

Request A Quote

China Factory Good Price Corner Doors Commercial Kfc Shop Front Store Front Door Double Automatic Swing Glass Entry Door

Product Details

Color:

Customizable

Position:

Shopping Malls, Hotels, Banks, Cafes

Glass:

Tempered Glass

Engineering Solutions Capabilities:

Graphic Design

Hardware:

Top Chinese Brand

Transport Package:

Inner Caron Box+Bubble Wrap+ Outer Carton Box

Trademark:

YIWANX

HS Code:

90328990

Payment & Shipping Terms

Minimum Order Quantity

10 Square Meters or 1 set

Price

US $80-150 / Square Meter

Packaging Details

wooden case

Delivery Time

25 -30 days after receiving of payment

Payment Terms

T/T, L/C

Supply Ability

10000 Units Per Month

Basic Info.

Special Function

Sunscreen,Soundproof,Heat Insulation,Rustproof

Color

Customizable

Certification

ISO9001, CE, SGS

Position

Shopping Malls, Hotels, Banks, Cafes

Surface Finishing

Powder Coated, Fluorocarbon Coated

Glass

Tempered Glass

After-Sale Service

Online Technical Support

Engineering Solutions Capabilities

Graphic Design

Design Style

Modern

Hardware

Chinese Top Brand

Guarantee

Ship Within 7 Days After Confirming Payment

Transport Package

Inner Caron Box+Bubble Wrap+ Outer Carton Box

Specification

Customizable

Trademark

YIWAN

Origin

Hefei, Anhui, China

HS Code

90328990

Production Capacity

10000 Units/Month

Packaging & Delivery

Package size per unit product

190.00cm * 215.00cm * 30.00cm

Gross weight per unit product

50.000kg

Product Description

Product	KFC Door
Material	aluminum alloy + glass
Specifications	Customized
Opening type	side-hung
Features	waterproof/sunscreen/soundproof/rust-proof/firm
Aluminum profile	high-grade thermal insulation circuit breaker/abnormal aluminum profile
Surface treatment	powder Coated, fluorocarbon Coated, anodizing, electrophoresis, wood grain heat transfer
Aluminum color	black, white, gray, coffee, customized.
Aluminum thickness	1.4mm, 1.6mm, 2.0mm, customized
Glass type	single-layer tempered glass, double-layer hollow tempered glass, frosted glass, laminated glass, low-E glass, radiation protection glass
Single glass	6mm, 8mm, 10mm, 12mm
Double glass	5mm+9A+5mm/5mm+12A+5mm/6mm+12A+6mm/ (glass can be 5mm/6mm)
Glass Color	Transparent
Hardware	OEM, ODM Chinese brand
Package	Protective foam + heat shrinkable plastic film/carton/wood packing or according to customer's special requirements
Delivery Time	7-25 working days after receipt of deposit and withdrawal confirmation.

Kfc Door Design Spring Floor Shop Front Door

Product Description

KFC door, the industry name in China, because it comes from KFC stores; it is suitable for hotels, shopping malls, office buildings, banks, coffee shops, showrooms and fast food restaurants and other places, and can be installed on both inner and outer doors.
It has the functions of temperature insulation, dust prevention, sand prevention, noise reduction and sound insulation, and shielding.

Component:
It is mainly composed of door frame, door leaf, door glass, large handle, large hinge, door closer, etc. This door type can be installed both indoors and outdoors.
Each door has two doors, the left door and the right door. Door leaf thickness 40-60mm.
The frame on one side of the door leaf and the door frame are connected by a large hinge, the door frame on the other side of the door leaf is equipped with a toggle-type upper and lower bolt, and a door closer is installed on one side of the beam on the top of the door leaf to connect with the door frame.
The large hinge of the door body adopts the bottom bolt tightening method, which is beautiful and durable.
Cross braces can be added to the middle part of the door leaf, which is beautiful and convenient for pedestrians to enter and exit.
The door leaf glass is tempered glass, and the door body is equipped with a stainless steel handle, which is beautiful and convenient for pedestrians to enter and exit.
Kfc Door Design Spring Floor Shop Front Door

Material part:
The outer frame of the door leaf is made of high-strength aluminum alloy profiles, with electrophoretic surface treatment, and the color is optional.
Windproof sand brushes and rubber strips are installed around the door leaf to ensure the sealing performance of the door body.
The door body is made of aluminum profile and tempered glass.
Kfc Door Design Spring Floor Shop Front Door

installation steps
1. Clean the door opening and eliminate the excess part. Make sure that both sides of the door opening are on a vertical line.
2. Install the top shaft part on the door frame.
3. Combine the three profiles of the door frame with screws or rivets
4. Install the ground shaft, open a square pit with a length of 170mm, a width of 120mm and a depth of 55mm on the ground, pour the mortar, and when fixing the ground shaft, from the center line of the top shaft to the center of the ground shaft bearing, fix the ground shaft, and after the cement is dry Proceed to the next step.
5. Install the upper and lower shafts of the door body.
6. Before installing the door body, you need to pay attention: loosen the anti-theft card position screw of the door leaf; before installing the door leaf, apply lubricating butter on the ground shaft to make the door leaf open and close freely and increase the service life.
7. Adjust the front, rear, left, right and up and down directions of the door leaf: loosen the cover plate and use a wrench to adjust the screw of the ground shaft; adjust the lower shaft on the door leaf, the specific method is to adjust the hexagonal screw on the lower shaft, adjust clockwise, the door leaf is upward, reverse The hour hand adjusts the door leaf downwards.
8. Tighten the anti-theft card screw.
Kfc Door Design Spring Floor Shop Front Door

Advantage:
It has chemical stability such as beautiful appearance, durability, various colors, easy to use, easy to open, heat preservation, cold and heat insulation, noise reduction and sound insulation, acid and alkali resistance, and corrosion resistance.

Sales & Services
Hefei Yiwan Architectural Decoration Engineering Co., Ltd.takes Quality, Efficiency and Service as the motto. So we provide 24 months warranty. During the warranty period, we can replace the parts of problem with new ones for free.

YIWAN have the most dedicated international service team. If you have any question or meet any problem, please feel free to contact us at any time, we'll reply you and help to solve the problem at the soonest.
Kfc Door Design Spring Floor Shop Front Door

OEM&ODM Service
We have professional design team, which can rebrand the customer's logo and company name as per customer's wishes.

YIWAN will never stop the pursuit of innovation with style. YIWAN would develop more innovative and market-oriented products in the future.

YIWAN Competitive Advantages
1.	We are direct manufacturer & we have professional self design team, which is capable of satisfying customers' most demanding needs
2.	Our products have World Class Quality Testing. We have certificates of SGS,CE, ISO9001.
3.	We use high quality carton box,damp-proof & breakage-proof bubble wrap, as well as wooden case packing to keep the goods intact even in long-distance sea transportation.
4.	Our special INSPECTION & QC department maintains a strict level of quality control. It ensures that all products are in compliance with specification. All goods and raw materials bought into the company go through strict inspection to ensure they are of good quality and correct.
5.	We have large production capability and sufficient safety stock to ensure quick lead-time.
6.	We are constantly innovating to launch new products every year.
7.	We provide 24-month warranty for all of our products.

FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
